Ordering Information
| Part No. | LAN port | Optical connector | Motherboard | Wifi function |
| HG8120C | 10/100/1000Mbps | SC/UPC | Class B+ | Optional |
Features
- GE EPON, GPON or XPON.
- Support port-based rate limitation and bandwidth control
- In compliant with ITU-T G.984 Standard
- Wi-Fi type optional,Wi-Fi series meet 802.11 n/b/g technical standards
- Support data encryption, group broadcasting, port Vlan separation, etc.
- Support Dynamic Bandwidth Allocation (DBA)
- Support ONU auto-discovery/Link detection/remote upgrade of software;
- Support port mode of VLAN configuration
- Support power-off alarm function, easy for link problem detection
- Support broadcasting storm resistance function
- Support port isolation between different ports
- FTTH
- Passive Optical LAN
| Technical item | 1GE |
| PON interface | 1 G/EPON port(EPON PX20+ and GPON Class B+) Wavelength:Tx1310nm,Rx 1490nm SC/UPC connector Receiving sensitivity: ≤-28dBm Transmitting optical power: 0~+4dBm Transmission distance: 20KM |
| LAN interface | 1 x 10/100/1000Mbps auto adaptive Ethernet interfaces.10/100/1000M Full/Half, 2 RJ45 connector |
| LED | 3, For Status of REG,SYS,LINK/ACT |
| Operating condition | Temperature: -30ºC~+70ºC Humidity: 10%~90%(non-condensing) |
| Storing condition | Temperature : -30ºC~+70ºC Humidity :10%~90%(non-condensing) |
| Power supply | DC 12V/0.5A(option) |
| Power consumption | ≤4W |
